Chess in C++













Greetings Readers.Next up is an game of chess implemented in C++.It is a 2 player game which make use of the graphics library in C++.The game also accepts Keyboard Inputs for movement.



The Program:

Its quite a lengthy program,but to simplify the program has been coded with Modules.

  • Graphics.h,dos.h,ctype.h are essential in the program.
  • Modules for each piece such as pawn,bishop,queen,king..etc is declared,which accept 3 integer parameters each.
  • The Initial part is the graphics initialisation part the method is initgraph for initialisation the graphics specify the path such as “F://TC//BGI//” in turboc where the graphics header files are located.
  • outtextxy() is similar to printf in console application,whereas outtext will output on the co-ordinates given as input.
  • The Input key strokes are checked for their validity using their ASCII values.
  • An array of 8×8 is declared for the chessboard.
  • The Script is given below:

#include<graphics.h>
#include<stdlib.h>
#include<stdio.h>
#include<iostream.h>
#include<conio.h>
#include<ctype.h> //For toupper
#include<dos.h> //For Delay</pre>
int board[8][8],turn=0,count1=0,count2=0;
int gameover();
char strFileName[15];
void printboard();
void wrongStart();
void initialize();
void cleartext();
void check();

//Prototypes
int pawn(int x,int y,int x1,int y1);
int horse(int x,int y,int x1,int y1);
int rook(int x,int y,int x1,int y1);
int bishop(int x,int y,int x1,int y1);
int queen(int x,int y,int x1,int y1);
int king(int x,int y,int x1,int y1);

void main()
{

//Graphics Initialization
int gdriver = DETECT;
int gmode;
initgraph(&gdriver,&gmode," ");

cleardevice();
cleardevice();

settextstyle(1,HORIZ_DIR,2);
setcolor(12);
outtextxy(50,10,"During the game Press:\n");
outtextxy(50,10,"______________________\n");

setcolor(6);
settextstyle(1,HORIZ_DIR,1.5);
outtextxy(50,80,"ESC to exit game");
outtextxy(50,100,"U to undo selection\n");
outtextxy(50,150,"\nPress any key to play ");
getch();
cleardevice();

cleartext();
initialize();
char ch;
int x=-1,y=-1,x1=-1,y1=-1;
setcolor(9);
outtextxy(10,400,"Player 1");
for(;;)
{
int game;
game=gameover();
if(game==0)
{
break;
}
// FILE *fp;
ch=getch();
if(ch==0){
ch=getch();
if(ch=='<'){

printboard();
cleartext();
x=-1;
y=-1;
x1=-1;
y1=-1;
setcolor(0);
outtextxy(10,400,"Player ?");
if(turn!=0){
check();
setcolor(2);

outtextxy(10,400,"Player 2");
}
else{
check();
setcolor(9);
outtextxy(10,400,"Player 1");
}
continue;
}
}

if(ch==27){
break;
}
else if(ch=='u'||ch=='U'){
x=-1;
x1=-1;
y1=-1;
y=-1;
cleartext();
continue;
}
if(x==-1){
ch=toupper(ch);
if(ch>=65 && ch<=72){
cout<<ch;
x=ch-65;
}
}
else if(y==-1)
{
if(ch>='1' && ch<='8')
{
cout<<ch;
y=ch-'1';
if(board[y][x]==0){
wrongStart();
x=-1;
y=-1;
}
else
{
if(turn==0)
{
if(board[y][x]<0)

//if Player 1 has selected a piece of Player 2
{
wrongStart();
x=-1;
y=-1;
}
}
else if(turn!=0)
{
if(board[y][x]>0)
{
wrongStart();
x=-1;
y=-1;
}
}
}
}
if(x!=-1 && y!=-1)
cout<<"\nenter final position ? ";
}
else if(x1==-1)
{ //Converting lower to upper case

ch=toupper(ch);
if(ch>=65 && ch<=72)
{
cout<<ch;
x1=ch-65;
}
}
else if(y1==-1)
{
if(ch>='1' && ch<='8')
{
cout<<ch;
y1=ch-'1';
}
int b=0,killed=0;

/////pawn/////

if(abs(board[y][x])>=9 && abs(board[y][x])<=16){ //if piece selscted has value greater than 8 and less than 17
b = pawn(x,y,x1,y1);

}//end pawn

//////horse//////

else if(abs(board[y][x])==2 || abs(board[y][x])==7){ //if piece selscted has value 2 and 7
b = horse(x,y,x1,y1);
}//end horse

////queen///

else if(abs(board[y][x])==4){ ////if piece selscted has value 4
b = queen(x,y,x1,y1);
}//end queen
///king///

else if(abs(board[y][x])==5){ //if piece selscted has value 5
b = king(x,y,x1,y1);
}//end king

///rook///

else if(abs(board[y][x])==1 || abs(board[y][x])==8){ //if piece selscted has value 1 and 8
b = rook(x,y,x1,y1);
}//end rook

///bishop///

else if(abs(board[y][x])==3 ||
abs(board[y][x])==6){ //if piece selscted has value 3 and 6
b = bishop(x,y,x1,y1);
}//end bishop

if(b==2){
if(abs(board[y][x])>=9 && abs(board[y][x])<=16){
char pp;

cout<<"\n\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\b\\bwhich piece Q,R,H,B";
pp=getch();
if(turn==0){
if(pp=='r')
board[y1][x1]=1;
else if(pp=='h')

board[y1][x1]=2;
else if(pp=='b')
board[y1][x1]=3;
else if(pp=='q')
board[y1][x1]=4;
}
else{
if(pp=='r')
board[y1][x1]=-1;
else if(pp=='h')
board[y1][x1]=-2;
else if(pp=='r')
board[y1][x1]=-3;
else if(pp=='q')
board[y1][x1]=-4;
}

board[y][x]=0;
killed =1;
}
else if(abs(board[y][x])==5){
if(board[y][x]==5){
if(count1==1);
wrongStart();}
else if(board[y][x]==-5){
if(count1==1);
wrongStart();}
else{
board[y][x+1]=board[y1][x1];
board[y][x+2]=board[y][x];
board[y1][x1]=0;
board[y][x]=0;
killed=1;
}
}
printboard();
}
else if(b==1)
{
if(turn==0)
{
if(board[y1][x1]<0)
{
board[y1][x1]=board[y][x];
board[y][x] = 0;

killed=1;
}
}
if(turn!=0)
{
if(board[y1][x1]>0)
{
board[y1][x1]=board[y][x];
board[y][x] = 0;
killed=1;
}
}
if(board[y1][x1]==0)
{
int temp=board[y][x];
board[y][x]=board[y1][x1];
board[y1][x1]=temp;
killed=1;
}
printboard();
}
x=-1;
y=-1;
x1=-1;
y1=-1;
setcolor(0);
outtextxy(30,340,"Check");
if(killed==0){
wrongStart();
continue;
}
cleartext();
setcolor(0);
outtextxy(10,400,"Player ?");
if(turn==0){
check();
turn=1;
setcolor(2);
outtextxy(10,400,"Player 2");
}
else{
check();
turn=0;
setcolor(9);
outtextxy(10,400,"Player 1");

}
}//end legal move
}//end for
}//end main

void printboard(){
for(int i=0;i<8;i++){
for(int j=0;j<8;j++){
if((i+j)%2==0)
setcolor(WHITE);
else
setcolor(BLACK);

outtextxy(270+(j*45),105+(i*45),"??");

if(board[i][j]<0)
setcolor(GREEN);
else if(board[i][j]>0)
setcolor(9);

if(abs(board[i][j])>=9 && abs(board[i][j])<=16){
outtextxy(270+(j*45),105+(i*45),"P");}

else if(abs(board[i][j])==1 || abs(board[i][j])==8){
outtextxy(270+(j*45),105+(i*45),"R");}

else if(abs(board[i][j])==2 || abs(board[i][j])==7){
outtextxy(270+(j*45),105+(i*45),"H");
}
else if(abs(board[i][j])==3 || abs(board[i][j])==6){
outtextxy(270+(j*45),105+(i*45),"B");
}
else if(abs(board[i][j])==4){
outtextxy(270+(j*45),105+(i*45),"Q");
}
else if(abs(board[i][j])==5){
outtextxy(270+(j*45),105+(i*45),"K");
}
}
}
}
void wrongStart()
{
cout<<"\nWrong Input\nPress any key to continue...";

char ch=getch();

if(ch==0){
getch();
}
for(int i=1;i<=30;i++)
for(int j=1;j<=4;j++)
{
gotoxy(i,j);
cout<<" ";
}
gotoxy(1,1);
cout<<"enter initial position ? ";
}

/////ClearText////
void cleartext(){
for(int i=1;i<=27;i++)
for(int j=1;j<=8;j++){
gotoxy(i,j);
cout<<" ";
}
gotoxy(1,1);
cout<<"enter initial position ? ";
}

/////Initialize////

void initialize(){
setcolor(WHITE);
rectangle(250,90,610,450);

// Board Printing
for (int i=250;i<560;i+=90)
for (int j=90;j<450;j+=90)
{
bar(i,j,i+45,j+45);
bar(i+45,j+45,i+90,j+90);
}

//Asigning the Values in the empty spaces
for(i=2;i<=5;i++)
for(j=0;j<=7;j++)
board[i][j] = 0;

for(j=0;j<=7;j++)
{
board[0][j] = j+1;
board[1][j] = j+9; //Pawns for player 1
board[7][j] = 0-(j+1);
board[6][j] = 0-(j+9); //Pawns for player 2
}
printboard();

setcolor(YELLOW);

outtextxy(265,55,"A");
outtextxy(310,55,"B");
outtextxy(355,55,"C");
outtextxy(400,55,"D");
outtextxy(445,55,"E");
outtextxy(490,55,"F");
outtextxy(535,55,"G");
outtextxy(580,55,"H");

outtextxy(220,105,"1");
outtextxy(220,150,"2");
outtextxy(220,195,"3");
outtextxy(220,240,"4");
outtextxy(220,285,"5");
outtextxy(220,330,"6");
outtextxy(220,375,"7");
outtextxy(220,420,"8");
}

////HORSE//////

int horse(int x,int y,int x1,int y1)
{
int a=0;
if((y1==y+2 && x1==x+1)||(y1==y+2 && x1==x-1)||(y1==y+1 &&
x1==x+2)||(y1==y+1 && x1==x-2)||(y1==y-1 && x1==x+2)||(y1==y-1 &&
x1==x-2)||(y1==y-2 && x1==x+1)||(y1==y-2 && x1==x-1)){
a = 1;
}
return a;
}

/////KING////

int king(int x,int y,int x1,int y1)
{
int a = 0;
if((y1==y+1 && x1==x)||(y1==y-1 && x1==x)||(y1==y+1 &&
x1==x+1)||(y1==y+1 && x1==x-1)||(y1==y-1 && x1==x+1)||(y1==y-1 &&
x1==x-1)||(y1==y && x1==x+1)||(y1==y && x1==x-1)){
a = 1;
}
/////CASTLING//////

else
if(board[y][x+1]==0&&board[y][x+2]==0&&(abs(board[y1][x1])
==abs(board[y][x+3])==1||abs(board[y1][x1])==
abs(board[y][x+3])==8)){

return 2;
}
if(a==1)
{
if(board[y][x]==5)
count1=1;
if(board[y][x]==-5)
count2=1;
}
return a;
}

//////BISHOP/////

int bishop(int x,int y,int x1,int y1)
{
int a=1,i;
if(abs(x1-x)!=abs(y1-y))
{
a=0;
}

if((x<x1)&&(y<y1))
{
for(i=1;(i+x)<x1;i++)
{
if(board[y+i][x+i]!=0)
a=0;
}
}

else if((x>x1)&&(y>y1)){
for(i=1;(x-i)>x1;i++){
if(board[y-i][x-i]!=0)
a=0;
}
}
else if((x>x1)&&(y<y1)){
for(i=1;(x-i)>x1;i++){
if(board[y+i][x-i]!=0)
a=0;
}
}
else if((x<x1)&&(y>y1)){
for(i=1;(y-i)>y1;i++){
if(board[y-i][x+i]!=0)
a=0;
}
}
return a;
}

////////QUEEN///////
int queen(int x,int y,int x1,int y1){
if(x==x1||y==y1){
//if queen moves in + direction
return rook(x,y,x1,y1);
}
else if(abs(x1-x)==abs(y-y1)){
//if queen moves in diagnol direction
return bishop(x,y,x1,y1);
}
else
return 0;
}

///ROOK////
int rook(int x,int y,int x1,int y1){
int a=1;
if(y1==y)
{
for(int i=x+1;i<x1;i++)
{
if(board[y1][i]!=0)

{
a = 0;
break;
}
}
for(i=x-1;i>x1;i--)
{
if(board[y1][i]!=0)
{
a = 0;
break;
}
}
}
else if(x1==x)
{
for(int i=y+1;i<y1;i++)
{
if(board[i][x1]!=0)
{
a = 0;
break;
}
}
for(i=y-1;i>y1;i--)
{
if(board[i][x1]!=0)
{
a = 0;
break;
}
}
}
else
{
a=0;
}
return a;
}

///PAWN/////
int pawn(int x,int y,int x1,int y1){
int a=0;
if(turn==0){

if(y==1){
if(y1==(y+2) && x1==x){
if(board[y1][x1]==0&&board[y+1][x]==0){
a = 1;
}
}
}
if(y1==y+1 && x1==x){
if(board[y1][x1]==0){
a = 1;
}
}
else if(y1==(y+1) && (x1==(x+1)||x1==(x-1))){
if(board[y1][x1]<0){
a = 1;
}
}
}
else if(turn==1){
if(y==6){
if( y1==(y-2) && x1==x){
if(board[y1][x1]==0&&board[y-1][x]==0){
a = 1;
}
}
}
if( y1==(y-1) && x1==x){
if(board[y1][x1]==0){
a = 1;
}
}
else if(y1==(y-1) && (x1==(x-1)||x1==(x+1))){
if(board[y1][x1]>0){
a = 1;
}
}
}
if(a==1)
{
if(turn==0)
{
if(y1==7)
return 2;
}
else

{
if(y1==0)
return 2;
}
}
return a;
}

////////Check////////

void check()
{
int t=0,i,j,x1,y1;
if(turn==0){
for(i=0;i<=7;i++)
{
for(j=0;j<=7;j++)
{
if(board[i][j]==-5)
{
y1=i; x1=j;
break;
}
}
}
for(j=0;j<=7;j++){
for(i=0;i<=7;i++){
if (t==1){
setcolor(9);
rectangle(20,335,100,365);
outtextxy(30,340,"Check");
break;
}

if(board[j][i]>=9 && board[j][i]<=16)
t = pawn(i,j,x1,y1);
else if(board[j][i]==2 || board[j][i]==7)
t = horse(i,j,x1,y1);
else if(board[j][i]==4)
t = queen(i,j,x1,y1);
else if(board[j][i]==1 || board[j][i]==8)
t = rook(i,j,x1,y1);
else if(board[j][i]==3 || board[j][i]==6)
t = bishop(i,j,x1,y1);

}// for
}// for
}//endif turn
else {
for(i=0;i<=7;i++){
for(j=0;j<=7;j++){
if(board[i][j]==5){
y1=i; x1=j;
break;
}
}
}
for(j=0;j<=7;j++){
for(i=0;i<=7;i++){
if (t==1){
setcolor(GREEN);
rectangle(20,335,100,365);
outtextxy(30,340,"Check");
break;
}

if(board[j][i]>=(-9) && board[j][i]<=(-16))
t = pawn(i,j,x1,y1);
else if(board[j][i]==(-2) || board[j][i]==(-7))
t = horse(i,j,x1,y1);
else if(board[j][i]==(-4))
t = queen(i,j,x1,y1);
else if(board[j][i]==(-1) || board[j][i]==(-8))
t = rook(i,j,x1,y1);
else if(board[j][i]==(-3) || board[j][i]==(-6))
t = bishop(i,j,x1,y1);

}// for
}// for
}// end else
}

//////GAME OVER/////
int gameover(){
int i,j,a=0,b=0;

for(i=0;i<=7;i++)
{
for(j=0;j<=7;j++)

{
if(board[i][j]==5)
b=1;
if(board[i][j]==-5)
a=1;
}
}
if(b==0)
{
setcolor(12);
outtextxy(30,340,"Game Over");
setcolor(GREEN);
outtextxy(30,300,"Player 1 Loses");
getch();
return 0;
}
else if(a==0)
{
setcolor(9);
outtextxy(30,340,"Game Over");
outtextxy(30,300,"Player 2 Loses");
getch();
return 0;
}
return 1;
}
<pre>

Script Download:



  • Click below to download Script



Note:All above code has been tested in Turbo C++ Compiler in Windows Xp Service Pack-3.

Also dont forget to Visit our part1 and part2 of the Basic C program series

Thank u for reading this Article hope it was useful !

-Regards

Sathesh Bm

About Sathesh Bm

Sathesh Bm has written 26 post in this website.

Engineer, Web Lover, Thinker, Blogger

Related Posts Plugin for WordPress, Blogger...
